| Base | |
| Engine power | 97.4 kW – 131 hp |
| Undercarriage length | 4.065 mm – 13.3 ft |
| Width over tracks | 2.490 mm – 8.2 ft |
| Mast | |
| Forward inclination | >10° |
| Backward inclination | >10° |
| Lateral inclination | ±5.5° |
| Mast vertical stroke | 2.250 mm – 7.4 ft |
| Rotary | |
| Nominal torque | 87 kNm – 64.170 lbf ft |
| Drilling speed (4+2) | 10 ÷ 30 rpm – spin off: 65 rpm |
| Rotary stroke | 11.000 mm – 36 ft |
| Winches | |
| Main winch line pull | 110×3 kN – 24.730×3 lbf |
| Aux winch line pull | 50 kN – 11.240 lbf |
| Crowd system | |
| Pull down force | 165 kN – 37.100 lbf |
| Extraction force | 290 kN – 65.200 lbf |
| Total rotary stroke | 13.250 mm – 43.5 ft |
| Excavation | |
| Max pile diameter | 750 mm – 30 in |
| Max pile depth | 16.5 m – 54.1 ft |
| Min working headroom | 8.650 mm – 28.3 ft |
| Transport | |
| Length | 11.500 mm – 37.7 ft |
| Width | 2.490 mm – 8.2 ft |
| Height | 3.150 mm – 10.3 ft |
| Weight | 28.500 kg – 62.800 lb |
