Base
Engine power 86 kW – 115 hp
Undercarriage length 3.755 mm – 12.3 ft
Width over tracks 2.490 mm – 8.2 ft
Mast
Forward inclination >10°
Backward inclination >10°
Lateral inclination ±6.5°
Mast vertical stroke 1.600 mm – 5.25 ft
Winches
Main winch line pull 80 kN – 18.440 lbf
Aux winch line pull 33 kN – 7.420 lbf
Excavation
Max wall depth* 16 m – 52.50 ft
Width of trench 300 ÷ 500 mm – 12 ÷ 20 in
Length of trench 2500 mm – 98.5 in
Grab closing force 120 kN – 27.000 lbf
Grab rotation +105° ÷ -35°
Min working headroom 6.450 mm – 21.2 ft
Transport
Length 10.000 mm – 32.8 ft
Width 2.490 mm – 8.2 ft
Height 2.900 mm – 9.5 ft
Weight 21.000 kg – 46.300 lb
