| Base | |
| Engine power | 53.7 kW – 73 hp |
| Undercarriage length | 3076 mm – 10 ft |
| Width over tracks | 2320 mm – 7.6 ft – 2320/2920 mm – 7.6/9.6 ft |
| Mast | |
| Forward inclination | >10° |
| Backward inclination | >10° |
| Lateral inclination | ±6° |
| Mast vertical stroke | 1.200 mm – 3.95 ft |
| Rotary | |
| Nominal torque | 34 kNm – 25.000 lbf ft |
| Drilling speed | 0 ÷ 55 rpm |
| Rotary stroke | 8.000 mm – 26.2 ft |
| Winches | |
| Main winch line pull | 58×3 kN – 13.040×3 lbf |
| Aux winch line pull | 17 kN – 3.820 lbf |
| Crowd system | |
| Pull down force | 85 kN – 19.100 lbf |
| Extraction force | 150 kN – 33.720 lbf |
| Total rotary stroke | 9.200 mm – 30.2 ft |
| Excavation | |
| Max pile diameter | 500 mm – 20 in |
| Max pile depth | 12.5 m – 41 ft |
| Min working headroom | 5.540 mm – 18.2 ft |
| Transport | |
| Length | 7.960 mm – 25.9 ft |
| Width | 2.320 mm – 7.6 ft |
| Height | 2.560 mm – 8.4 ft |
| Weight | from 13.000 kg – 28.650 lb |
